Loos Galvanized Steel Vinyl Coated Wire Rope, 7x7 Strand Core, Fluorescent Green, 1/8" Bare OD, 5/16" Coated OD, 250' Length, 3700 lbs Breaking Strength
You looking to find the "Loos Galvanized Steel Vinyl Coated Wire Rope, 7x7 Strand Core, Fluorescent Green, 1/8" Bare OD, 5/16" Coated OD, 250' Length, 3700 lbs Breaking Strength" Good news! You can purchase Loos Galvanized Steel Vinyl Coated Wire Rope, 7x7 Strand Core, Fluorescent Green, 1/8" Bare OD, 5/16" Coated OD, 250' Length, 3700 lbs Breaking Strength with secure price and compare to view update price on this product. And deals on this product is available only for limited time.Price:
Product Feature
- Fluorescent green-colored wire rope for ease of recognition
- Galvanized steel is coated with a thin layer of zinc that protects underlying material from corrosion and provides rust resistance
- Galvanized steel remains ductile over long work periods, and usually has a higher breaking strength than stainless steel
- Vinyl [Polyvinyl Chloride (PVC)]-coating is a hard, durable plastic that resists most chemicals and has excellent dimensional stability for ease of operation
- 7x7 strand core is stronger but less flexible than 6x19 and 6x36 class constructions
Product Description
Galvanized steel vinyl-coated wire rope with 7x7 standard construction is commonly used in pulleys, and in aircraft and automotive controls. This wire rope is fluorescent green-colored for ease of recognition. Galvanized steel wire rope is coated with a thin layer of zinc that protects underlying material from corrosion and provides rust resistance. This strong material remains ductile over long work periods, and has a higher breaking strength than stainless steel. Vinyl, also called Polyvinyl Chloride (PVC), is corrosion-resistant, lightweight, and has high strength. It resists reactions with acids, gasoline, alcohol, and hydrocarbons. It is flexible and resistant to weather and ultra-violet (UV) rays. Vinyl coating is a hard, durable plastic that resists most chemicals, has excellent dimensional stability, and can be sterilized. It resists oil, has absorbs low levels of moisture, and is non-conductive. 7x7 strand core has seven strands of wire rope with seven wires in each strand formed helically around a strand core. 7x7 strand core is stronger but less flexible than 6x19 and 6x36 class constructions.
Wire rope, also called wire cable, is an assembly of wire strands formed helically around a central core. It is used for pulling, lifting, rigging, hoisting, and motion-control applications most commonly found in the manufacturing, marine, oil, mining, fiber-optics, aircraft, automotive accessory, and construction industries. A combination of characteristics including material, finish, construction, diameter, length, and breaking strength combines to give each rope its performance ability. Wire rope materials are selected for properties such as strength, elasticity, conductivity, and chemical- and weather-resistance. For strength purposes, most wire rope is made of bright (uncoated or bare) wire. However, it is also produced in a variety of finishes, such as polypropylene (PE), vinyl (PVC), or nylon. These coatings can increase overall durability and strength, and allow for specific use. The breaking strength for wire rope is the strength at which new wire rope will fail under a stationary load. Breaking strength is not considered safe working load (SWL) limit.
</p>Loos Galvanized Steel Vinyl Coated Wire Rope, 7x7 Strand Core, Fluorescent Green, 1/8" Bare OD, 5/16" Coated OD, 250' Length, 3700 lbs Breaking Strength Review
Very nice, have used this style of cable for several projects, including homemade dog leashes and as overhead wires for a kiwi arbor. The vinyl coating leaves the length of cable smooth and protected from corrosion. I thought of using plasti-dip to coat the crimps and loops at the ends, but I decided to just leave them alone and see how they hold up.Be aware that the vinyl coating MUST be stripped back where you crimp cable ferrules, otherwise don't count on it being very strong at all.
Also, shop around for different colors/lengths - at the time I bought the green 25' length was VERY cheap and worked perfect for my application, but pricing does not seem to be very consistent across similar products.
Most of the consumer Reviews tell that the "Loos Galvanized Steel Vinyl Coated Wire Rope, 7x7 Strand Core, Fluorescent Green, 1/8" Bare OD, 5/16" Coated OD, 250' Length, 3700 lbs Breaking Strength" are high quality item. You can read each testimony from consumers to find out cons and pros from Loos Galvanized Steel Vinyl Coated Wire Rope, 7x7 Strand Core, Fluorescent Green, 1/8" Bare OD, 5/16" Coated OD, 250' Length, 3700 lbs Breaking Strength ...
